Extenda-Lift 600 – 8100025

Description

With the Magswitch ExtendaLift 600, you can pick up and move steel on the ground without bending over and using your hands. Twist the handle to turn On/Off 600 pounds of magnetic holding force. Safely lift a valve box with ease as well as hot, sharp, or dirty steel without touching it. Ideal for cities and utilities, valve box and small lid removal.



FEATURES & BENEFITS

600 lbs (272 kg) of hold force.

No need to bend over and pick up materials.

Magnetic field turns completely on and off mechanically.

Does not use an electrical power source.

Instantly attaches to and removes valve box covers.

Our safety lock keeps magnets on until they’re turned off.

Easy on/off control for precise positioning.

Lightweight, sturdy and compact.







SPECIFICATIONS

Max Breakaway: 478 lbs (216.8 kg) on 2” steel

Full Saturation Thickness: 2” (50.8 mm)

2:1 Shear Working Load: 45 lbs (20.4 kg)

Product Weight: 5.3 lbs (2.4 kg)

Dimensions: 4 x 3.9 x 28.2 in (101.6 x 99 x 716.2 mm)

1. Magnetic Pole Footprint: 116.8 mm x 66 mm
